DALI Control 2×64 Gateway, 4SU MDRC. The gateway is DALI-2 certified. With dimmable colour adjustment by HSV control. 2 DALI outputs for max. 2 x 64 ECGs. Individual control of up to 64 ECGs / 16 DALI groups per output. Supports DALI and DALI-2 standard, as well as DALI ECG DT6 / DT8. Innovative HSV color control, RGB, RGBW and XY colour according to DALI DT8 standard. Tunable White, color temperature control. Integrated colour control module for time dependent controlling of the luminous colour in up to 300 steps. Operation modes like normal operation, continuous operation, night operation, stairwell and panic operation, Manual operation. 16 scenes with individual dimming times. Energy saving function for switching off the ECGs in the DALI groups (via additional KNX switch actuator). Fault detection of lamp faults and faulty ECGs. Quick exchange of ECG. Free DCA app for commissioning the DALI bus system and configuration of the scenes and time control. Commissioning with ETS5. 3 year warranty.

DALI Control 64 Gateway, 4SU MDRC. The gateway is DALI-2 certified. With dimmable colour adjustment by HSV control. Individual control of up to 64 ECGs / 16 DALI groups. Supports DALI and DALI-2 standard, as well as DALI ECG DT6 / DT8. Innovative HSV color control, RGB, RGBW and XY colour according to DALI DT8 standard. Tunable White, color temperature control. Integrated colour control module for time dependent controlling of the luminous colour in up to 300 steps. Operation modes like normal operation, continuous operation, night operation, stairwell and panic operation, Manual operation. 16 scenes with individual dimming times. Energy saving function for switching off the ECGs in the DALI groups (via additional KNX switch actuator). Fault detection of lamp faults and faulty ECGs. Quick exchange of ECG. Free DCA app for commissioning the DALI bus system and configuration of the scenes and time control. Commissioning with ETS5. 3 year warranty.

Dimming Actuator 2-fold, 3SU MDRC, 250 W, 230 V AC, with active power measurement. Dimming Actuator 2-fold, 3SU MDRC, 250 W, 230 V AC with active power measurement, for switching and dimming. Nominal power output 2 x 250 W or 1 x 500 W. Optimized for dimmable LED lights > 2 W. For HV- Halogen lights and NV- Halogen lights with transformer/EVG. Operation in leading-edge or trailing-edge selectable. Active power measurement. Integrated diagnostic function with plain text message. Overcurrent-/short circuit- and temperature protection with message. Time functions (switch-on/switch-off delay, staircase light function). Automatic time dependent dimming. Softstart, global and individual dimming speed. Day/Night function. Parallel operation of 2 channels with 500 W total power output. Push Button and LED indicator for each channel. Separate L-/N- connections for each channel (different phases possible L1, L2, L3). 3 year warranty.

Dimming Actuator 4-fold, 4SU MDRC, 1-10 V, RGBW. Control device for 1-10 V electronic transformers with relays. Current max. 16 A, capacitive load max. 140 μF. Push Button for manual operation and indicator for each channel. To control 1-10V electronic transformers (ECG). With RGBW functionality. RGB und HSV control with extensive colour functions. Offers control voltage up to 30 ECG (each channel). Voltage reversal protection. Embedded switching relays for 30 ECG / 30 W, 20 ECG / 58 W, 15 ECG / 2×36 W, 10 ECG / 2×58 W. Adjustable switch-on behaviour. Minimum/maximum brighness value adjustable. Adjustable dimming speed. Central switching functions. 8 scenes per channel. 1 Bit automatic function. 3 year warranty.
